Product Details:
|
| Model NO.: | 005 | Types Of Suspension Systems: | Leaf Spring Suspension |
|---|---|---|---|
| Shape: | Flatbed | Axle Number: | 3 Axles |
| Tire Number: | 12 | Self-dumping: | Not Self-dumping |
| ABS Anti-lock Braking System: | No ABS Anti-lock Braking System | Material: | Steel |
| Condition: | New | Kingpin: | Jost Brand, 2" Or 3" |
| Tire Brand: | Double-Coin Optional | Landing Gear: | Jost Or Fuwa Brand |
| Transport Package: | Naked Or Waxed Before Shipment | Specification: | 13000*2500*3250mm |
| Origin: | China | HS Code: | 87163990 |
| Supply Ability: | 600sets/Month |
| Place of Origin: | Shandong,China |
| Material: | Steel |
| Color: | Customer's Request |
| Tare Weight: | 8000kg |
| landing gear: | 28 tons, 2 pieces |
| Overall Dimension: | 13000mm*2550mm*2650mm(Customers can choose) |
| Hydraulic Jack: | Full set of HYVA hydraulic system, front setting telescopic jack |
| Axle: | 3 axles(Brand optional) |
| lockset: | Each vehicle is equipped with 2 container locks, 8 sets of container specific locks, and equipped with rope hooks and tighteners |
| traction pin: | JOST 90# |
| brake system: | WABCO |
| Bottom plate and box board: | Bottom plate: 3mm Box plate: 1.5mm |
| Longitudinal beam (mm): | Upper wing plate: 14mm Abdominal plate: 8mm Lower wing plate: 16mm |
| Paiting: | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
| Application: | Transport all kinds of Mineral/Coal/Stone/Sand/Cargo Loading |
| Supply Ability: | 600 Piece/Pieces per Month |
| Service: | Vehicle design can be carried out according to customer requirements |
